AAE COM AAE40-VGA-VGA Camera Sync Terminal Adapter

About this product

A 15-pin VGA (Video Graphics Array) to VGA data connector is commonly used to transmit video signals between devices such as computers, monitors, projectors, and TVs. Here's a detailed description of each pin in the connector:Red Video (Analog): Transmits the red component of the video signal.Green Video (Analog): Transmits the green component of the video signal.Blue Video (Analog): Transmits the blue component of the video signal.Monitor ID Bit 2: Used for monitor identification and configuration.Ground: Provides electrical grounding for the signal and the device.Red Ground: Ground connection for the red video signal.Green Ground: Ground connection for the green video signal.Blue Ground: Ground connection for the blue video signal.No Connection: This pin is not connected and is typically left unused.Sync Ground: Ground connection for the sync signals.Monitor ID Bit 0: Used for monitor identification and configuration.Data Ground: Ground connection for the data signals.Horizontal Sync (Analog): Transmits the horizontal synchronization signal.Vertical Sync (Analog): Transmits the vertical synchronization signal.Monitor ID Bit 1: Used for monitor identification and configuration.These pins facilitate the transmission of analog video signals and provide connections for synchronization and monitor identification. The VGA connector is widely used for its compatibility and simplicity in transmitting video signals.
